€342.00*
- 3-year guarantee
- 2.5% advance payment discount
- If you use the payment method in advance by bank transfer, 2.5% of the purchase amount will be automatically deducted at the checkout.
No longer available
.jpg){kind=icon}
.jpg){kind=icon}
.jpg)
.jpg)
.jpg)
.jpg)
Description
The Owon XDM3051 is a powerful digital desktop multimeter from the XDM series that offers a significantly higher resolution and accuracy than the XDM3041 with 5½ digits. It is ideal for laboratory, development, training and service applications where precise measurement results and finer gradations are required for low voltages and currents.
With a resolution of up to 1,000,000 counts and a DC voltage accuracy of up to 0.015 % + 0.004, the XDM3051 offers measured values at a professional level. Compared to the XDM3041, it has finer measuring ranges - e.g. for DC voltage (200 mV / 2 V / 20 V / 200 V / 1000 V) - and therefore allows even more precise recording of small signals.
the device can be controlled, programmed and integrated into automated test benches via USB, RS-232 and LAN. Results can also be saved directly to USB memory sticks. With a measurement rate of up to 150 readings per second, the XDM3051 is also ideally suited for dynamic tests.
Features
- 5½ digits, up to 1,000,000 counts
- Very high accuracy: e.g. DCV up to ±0.015 % + 0.004
- Fine measuring ranges (e.g. DCV from 200 mV) for precise low voltage measurements
- True RMS for AC voltage and current
- High measuring speed: up to 150 values/second
- Display modes: numerical, bar graph, histogram, trend curve
- 4.0" colour display (480×320)
- Interfaces: USB device/host, RS-232, LAN, external trigger, SCPI-compatible
- Direct data storage on USB memory
Technical Data
| Model |  XDM3051 |
| Digits (digits) | 5½ |
| Display (counts) | up to 1 000 000 |
| Reading speed | up to 150 readings/s |
| Display | 4.0″ LCD, 480 × 320 |
| True RMS | AC voltage & AC current |
| Double line display | supported |
| Interfaces | USB Device/Host, RS-232, LAN, external trigger (Wi-Fi optional) |
| Remote control | SCPI supported |
| DC voltage (ranges) | 200 mV, 2 V, 20 V, 200 V, 1000 V |
| AC voltage (ranges, true RMS) | 200 mV, 2 V, 20 V, 200 V, 750 V |
| DC current (ranges) | 200 µA, 2 mA, 20 mA, 200 mA, 2 A, 10 A |
| Resistance (ranges) | 200 Ω, 2 kΩ, 20 kΩ, 200 kΩ, 2 MΩ, 10 MΩ |
