Siglent Vector Network Analyser

Name: T&M eVision Instruments GmbH
Address: Jahnstraße 12, Forstinning, 85661, DE
Telephone: +49 8121 767149 0
Price range: €€€

Series comparison - Siglent vector network analyzers

Series comparison	Frequency range	Channels	dynamic range	Trace noise	Output area
SNA6000A	100 kHz to 13.5/26.5 GHz	2/4	135 dB	0.005 dB eff., 0.012° eff.	-55 dBm ~ +10 dBm
SNA5000X-E	9 kHz to 6.5 GHz	2	117 dB	0.006 dB rms, 0.05° rms	-40 dBm ~ 0 dBm
SNA5000A	9kHz ~ 4.5/8.5GHz and 100kHz ~ 13.5/26.5GHz	2/4	125 dB	0.003 dB eff., 0.03 °eff.	-55 ~ +10 dBm
SHN900A	30 kHz – 14/20/26.5 GHz	2	100 dB	0.003 dB eff., 0.03° eff.	-45 dBm ~ +10 dBm
