Benchtop Oscilloscopes

33.52 %

Details

STO1104C Tablet Oscilloscope

Product Nr.: STO1104C

The STO1104C is an tablet oscilloscope with classic control knobs and touch screen.

Features

Compact oscilloscope with 4 channels
Bandwidth 100 MHz
1 GS / s real-time sampling rate.
Replaceable battery
Up to 28 Mpts memory depth.
Acquisition rate of up to 80,000 Wfms / s.
8 "/ 8" industrial LCD, 800x600 resolution, capacitive multi-point touchscreen.
Android system, quick response to operation.
Interfaces: Ethernet / LAN, WiFi, USB 2.0 host & device; HDMI.
Connection for probe calibration.
Bus trigger and decoding supported: UART, I²C, SPI, CAN, LIN.
PC software, iOS and Android mobile app for remote control of the oscilloscope.
Built-in 8G memory for waveform and video recording.
Lithium battery, battery life up to 5 hours.
Screen sharing via WiFi, USB and HDMI

Product is discontinued

38.66 %

Details

STO1152C Tablet Oscilloscope

Product Nr.: STO1152C

The STO1152C is an tablet oscilloscope with classic control knobs and touch screen.

Features

Compact oscilloscope with 2 channels
Bandwidth 150 MHz
1 GS / s real-time sampling rate.
Replaceable battery
Up to 28 Mpts memory depth.
Acquisition rate of up to 80,000 Wfms / s.
8 "/ 8" industrial LCD, 800x600 resolution, capacitive multi-point touchscreen.
Android system, quick response to operation.
Interfaces: Ethernet / LAN, WiFi, USB 2.0 host & device; HDMI.
Connection for probe calibration.
Bus trigger and decoding supported: UART, I²C, SPI, CAN, LIN.
PC software, iOS and Android mobile app for remote control of the oscilloscope.
Built-in 8G memory for waveform and video recording.
Lithium battery, battery life up to 5 hours.
Screen sharing via WiFi, USB and HDMI

Product is discontinued

40.85 %

Details

STO1152E Tablet Oscilloscope

Product Nr.: STO1152E

The STO1152E is an tablet oscilloscope with classic control knobs and touch screen.

Features

Compact oscilloscope with 2 channels
Bandwidth 150 MHz
1 GS / s real-time sampling rate.
Replaceable battery
Up to 70 Mpts memory depth.
Acquisition rate of up to 130,000 Wfms / s.
8 "/ 8" industrial LCD, 800x600 resolution, capacitive multi-point touchscreen.
Android system, quick response to operation.
Interfaces: Ethernet / LAN, WiFi, USB 2.0 host & device; HDMI.
Connection for probe calibration.
Bus trigger and decoding supported: UART, I²C, SPI, CAN, LIN.
PC software, iOS and Android mobile app for remote control of the oscilloscope.
Built-in 8G memory for waveform and video recording.
Lithium battery, battery life up to 5 hours.
Screen sharing via WiFi, USB and HDMI

Product is discontinued

STO1004 Tablet Oscilloscope

Product Nr.: STO1004

The STO1004 is a 4-channel tablet oscilloscope with 100 MHz bandwidth, classic control buttons and touch screen.

Features

Compact oscilloscope with 4 channels
Bandwidth 100 MHz
1 GS/s real-time sampling rate.
Android operating system
Replaceable battery
Up to 70 Mpts memory depth.
130.000 Wfms/s acquisition rate
8"/20.3 cm industrial LCD, 800x600 resolution, capacitive multi-point touch screen.
Interfaces: Wi-Fi, USB 3.0/2.0 host, USB Type-C, HDMI, trigger output, ground
Connection for probe calibration.
Bus trigger and decoding supported: UART, I²C, SPI, CAN, LIN.
PC software, iOS and Android mobile app for remote control of the oscilloscope.
Built-in 32GB memory for waveform and video recording.
7500mAh lithium battery, battery life up to 5 hours.
Screen sharing via wifi, USB and HDMI

€549.00*

STO2002 Tablet Oscilloscope

Product Nr.: STO2002

The STO2002 is a 2-channel tablet oscilloscope with 200 MHz bandwidth, classic control buttons and touch screen.

Features

Compact oscilloscope with 2 channels
Bandwidth 200 MHz
1 GS/s real-time sampling rate.
Android operating system
Replaceable battery
Up to 70 Mpts memory depth.
130.000 Wfms/s acquisition rate
8"/20.3 cm industrial LCD, 800x600 resolution, capacitive multi-point touch screen.
Interfaces: Wi-Fi, USB 3.0/2.0 host, USB Type-C, HDMI, trigger output, ground
Connection for probe calibration.
Bus trigger and decoding supported: UART, I²C, SPI, CAN, LIN.
PC software, iOS and Android mobile app for remote control of the oscilloscope.
Built-in 32GB memory for waveform and video recording.
7500mAh lithium battery, battery life up to 5 hours.
Screen sharing via wifi, USB and HDMI

€459.00*

SDS1052DL+ Oscilloscope

Product Nr.: SDS1052DL+

The SDS1052DL+ oscilloscope offers a bandwidth of 50 MHz, as well as 2 channels that can be used simultaneously.

Features

Supports multilingual display and embedded help
Screen saver from 1 minute to 5 hours
Digital filter and waveform recording function
Shortcut memory function key
7-inch TFT LCD display with a resolution of 800 * 480
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11), Pass/Fail.

€259.00*

SDS1102CML+ Oscilloscope

Product Nr.: SDS1102CML+

The SDS1052DL+ oscilloscope offers a bandwidth of 50 MHz, as well as 2 channels that can be used simultaneously.

Features

Supports multilingual display and embedded help
Screen saver from 1 minute to 5 hours
Digital filter and waveform recording function
Shortcut memory function key
7-inch TFT LCD display with a resolution of 800 * 480
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11), Pass/Fail.

€279.00*

SDS1104X-U Oscilloscope

Product Nr.: SDS1104X-U

The Siglent SDS1104X-U has a bandwidth of 200 MHz and a maximum recording length of 14 Mpts.

Features

100 MHz bandwidth
Real-time sampling rate up to 1 GSa / s
128 kpts FFT, supports peaks and markers
The latest generation of SPO technology
Signal acquisition rates up to 100,000 wfm / s (normal mode) and 400,000 wfm / s (sequence mode)
Supports 256-level intensity grading and color temperature display modes
Record length up to 14Mpts and digital trigger system
Intelligent trigger: edge, slope, pulse width, window, runt, interval, timeout (dropout), pattern
Serial bus triggering and decoding (standard), supports IIC, SPI, UART, CAN, LIN protocols incl. video trigger, supports HDTV
10 types of one-button shortcuts, supports auto setup, standard, cursor, measure, roll, history, view / keep, clear sweep, zoom.
Auto measurement function for 38 parameters, plus measurement statistics, zoom, gating, math, history, and reference functions.
History waveform recording function (history) (maximum length of recorded waveform is 80,000 frames)
Mathematical functions (FFT, addition, subtraction, multiplication, division, integration, differential, square root)
Large 7-inch TFT LCD display with 800 * 480 resolutionT LCD display with 800 * 480 resolution
Segmented acquisition (sequence) mode divides the maximum record length into multiple segments (up to 80,000) according to the trigger conditions set by the user
Bode plot function controls external generator (SIGLENT SDG or SAG generators, 4-channel models only)

€359.00*

5.59 %

SDS1104X-E Oscilloscope

Product Nr.: SDS1104X-E

The Siglent SDS1104X-E is suitable for a wide range of applications with a bandwidth of 100 MHz & countless software features.

Features

100 MHz bandwidth
4 channels
Intelligent trigger: Edge, Slope, Pulse Width, Window, Runt, Interval, Timeout (Dropout), and Pattern
Serial bus triggering and decoding: IIC, SPI, UART, RS232, CAN and LIN
Video trigger and supports HDTV
Low background noise and voltage scales from 500 μV/div to 10 V/div
10 types of one-button key combinations, supports auto setup, standard, cursor, measure, roll, history, display / persistence, clear sweep, zoom and printing
Segmented acquisition mode (sequence), which divides the maximum record length into multiple segments (up to 80,000), depending on the trigger conditions set by the user, with a very small dead time segment to capture the qualification event.
History Waveform Record (History) function, the maximum length of the recorded signal waveform is 80,000 frames.
Automatic measurement function for 38 parameters, supports statistics, gating measurement, math measurement, history measurement and ref measurement
1 Mpts FFT
Real measurements and calculations can use all 14 Mpts of memory
Preset key can be customized for user settings or factory default settings
Security erase mode
High speed hardware based pass / fail function
Large 7 inch TFT LCD display with 800 * 480 resolution
Multiple interface types: USB host, USB device (USB-TMC), LAN (VXI-11), Pass / Fail, Trigger Out
Supports SCPI remote control commands
Multilingual display and embedded help
Browser control / onboard web page for software-free monitoring
Bode plotting function controls external generator (SIGLENT SDG or SAG generators)

€405.00* €429.00*

Siglent SDS1202X-E Oszilloskop Rückseite

SDS1202X-E Oscilloscope

Product Nr.: SDS1202X-E

The Siglent SDS1202X-E is suitable for a wide range of applications with a bandwidth of 200 MHz & countless software features.

Features

Intelligent triggers: edge, slope, pulse width, window, run, interval, timeout (dropout) and pattern
Free serial bus triggering and decoding for I2C, SPI, UART, RS232, CAN and LIN
Video trigger and HDTV support
Low background noise and voltage scales from 500 μV / div to 10 V / div
Confugable DeepL access function, supports auto setup, default, cursors, measure, roll, history, display/persist, clear sweep, zoom and print
Segmented acquisition mode (Sequence), which divides the maximum recording length into multiple segments (up to 80,000), according to the trigger conditions set by the user, with a very small dead time segment to capture the qualifying event.
Waveform recording (history), the maximum length of the recorded waveform is 80,000 frames.
Automatic measurement function for 38 parameters, supports statistics, gating measurement, mathematical measurement, history measurement and ref measurement
Large 1 Mpts FFT function for a high number of interpolation points
Real measurements and mathematical calculations can use the whole 14 Mpts of memory
High speed hardware based pass/fail function
Large 7-inch TFT LCD display with 800 * 480 resolution
Multiple interface types: USB host, USB device (USB-TMC), LAN (VXI-11), Pass / Fail, Trigger Out
Supports SCPI remote control commands
Intuitive menu navigation and embedded help
Browser control/onboard web page for software-free monitoring (4-channel models only)
Bode plot function controls external generator (SIGLENT SDG or SAG generators, 4-channel models only)

€339.00*

SDS1204X-E Oscilloscope

Product Nr.: SDS1204X-E

The Siglent SDS1204X-E is suitable for a wide range of applications with a bandwidth of 200 MHz & countless software features.

Features

200 MHz bandwidth
4 channels
Intelligent trigger: Edge, Slope, Pulse Width, Window, Runt, Interval, Timeout (Dropout), and Pattern
Serial bus triggering and decoding: IIC, SPI, UART, RS232, CAN and LIN
Video trigger and supports HDTV
Low background noise and voltage scales from 500 μV/div to 10 V/div
10 types of one-button key combinations, supports auto setup, standard, cursor, measure, roll, history, display / persistence, clear sweep, zoom and printing
Segmented acquisition mode (sequence), which divides the maximum record length into multiple segments (up to 80,000), depending on the trigger conditions set by the user, with a very small dead time segment to capture the qualification event.
History Waveform Record (History) function, the maximum length of the recorded signal waveform is 80,000 frames.
Automatic measurement function for 38 parameters, supports statistics, gating measurement, math measurement, history measurement and ref measurement
1 Mpts FFT
Real measurements and calculations can use all 14 Mpts of memory
Preset key can be customized for user settings or factory default settings
Security erase mode
High speed hardware based pass / fail function
Large 7 inch TFT LCD display with 800 * 480 resolution
Multiple interface types: USB host, USB device (USB-TMC), LAN (VXI-11), Pass / Fail, Trigger Out
Supports SCPI remote control commands
Multilingual display and embedded help
Browser control / onboard web page for software-free monitoring
Bode plotting function controls external generator (SIGLENT SDG or SAG generators)
Bode plot function controls external generator (SIGLENT SDG or SAG generators, 4-channel models only)

€659.00*

Details

SDS2202X-E Oscilloscope

Product Nr.: SDS2202X-E

The Siglent SDS2202X-E has a bandwidth of 200 MHz and a standard recording length of 28 Mpts.

Features

200 MHz Bandbreite
2 Kanäle
Intelligente Auslöser: Edge, Slope, Pulse Width, Window, Runt, Interval,Time out (Dropout), Pattern
Serielle Bus-Triggerung und -Decodierung (Standard), unterstützt die Protokolle IIC, SPI,
UART, CAN, LIN
Geringes Hintergrundrauschen mit Spannungsskalen von 500μV / div bis 10V / div
10 Arten von Ein-Tasten-Tastenkombinationen, unterstützt Auto Setup, Default, Cursors, Measure, Roll, History, Display/Persist, Clear Sweep, Zoom und Print
Aufzeichnungsfunktion der Signalkurve (Verlaufsfunktion) (die maximale Länge der aufgezeichneten Signalkurve beträgt 80.000 Frames)
1 Mpt FFT
Mathematik- und Messfunktionen verwenden alle abgetasteten Datenpunkte im Speicher (bis zu 28 Mpts)
Mathematische Funktionen (FFT, Addition, Subtraktion, Multiplikation, Division, Integration, Differential, Quadratwurzel)
Großes 7 Zoll TFT-LCD-Display mit 800 * 480 Auflösung
Unterstützt mehrsprachige Anzeige und eingebettete Online-Hilfe

Produkt abgekündigt

Details

SDS2352X-E Oscilloscope

Product Nr.: SDS2352X-E

The Siglent SDS2352X-E has a bandwidth of 350 MHz and a standard recording length of 28 Mpts.

Features

350 MHz bandwidth
2 channels
Intelligent triggers: Edge, Slope, Pulse Width, Window, Runt, Interval,Time out (Dropout), Pattern
Serial bus triggering and decoding (standard), supports protocols IIC, SPI,
UART, CAN, LIN
Low background noise with voltage scales from 500μV / div to 10V / div
10 types of one-button key combinations, supports auto setup, default, cursors, measure, roll, history, display/persist, clear sweep, zoom, and print
Recording function of signal curve (history function) (the maximum length of recorded signal curve is 80,000 frames)
1 Mpt FFT
Math and measurement functions use all sampled data points in memory (up to 28 Mpts)
Math functions (FFT, addition, subtraction, multiplication, division, integration, differential, square root)
Large 7 inch TFT LCD display with 800 * 480 resolution
Supports multilingual display and embedded online help

Produkt abgekündigt

SDS2102X Plus Oscilloscope

Product Nr.: SDS2102X Plus

The SDS2102X Plus oscilloscope from Siglent offers a bandwidth of 100 MHz, as well as 4 analog and 16 digital channels.

Features

Available bandwidths: 350 MHz, 200 MHz and 100 MHz
Real-time sampling rate of up to 2 GSa / s. A 500 MHz bandwidth upgrade option is available for 350 MHz models.
SPO technology
Signal acquisition rates up to 120,000 wfm / s (normal mode) and 500,000 wfm / s (sequence mode)
Supports intensity gradation and color temperature display modes with 256 levels
Recording length up to 200 Mpts / channel, total 400 Mpts for all 4 channels
Digital trigger system
Intelligent trigger: edge, slope, pulse, window, runt, interval, failure, pattern and video (HDTV supported). Trigger zone simplifies advanced triggering
Serial bus triggering and decoder, supports I 2 C, SPI, UART, CAN, LIN (standard) and CAN FD, FlexRay, I 2 S and MIL-STD-1553B protocols (optional)
Low background noise with voltage scales from 0.5 mV / div to 10 V / div
10-bit mode provides higher resolution and lower noise
Segmented acquisition mode (sequence mode) where the maximum record length is divided into multiple segments (up to 90,000) according to user-specified trigger conditions, with a very short dead time between segments for acquisition of the qualifying event
History waveform recording function (history) for up to 90,000 triggered waveforms (frames)
Automatic measurement function for more than 50 parameters, supports statistics with histogram and trend
Two math tracks support 2 Mpts FFT, +, -, x, ÷, d / dt, ∫dt, √, average, ERES and formula editor
Numerous data processing and analysis functions such as search, navigate, mask test, Bode plot, power analysis (optional), and counter
16 digital channels (optional)
Built-in 50 MHz waveform generator (optional)
Large 10.1-inch TFT LCD display with 1024 × 600 resolution; capacitive touchscreen supports multi-touch gestures
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11 / Telnet / Socket), Pass / Fail, Trigger Out
Built-in web server supports remote control via LAN port using a web browser. Supports SCPI remote control commands

€899.00*

SDS2104X Plus Oscilloscope

Product Nr.: SDS2104X Plus

The SDS2104X Plus oscilloscope from Siglent offers a bandwidth of 100 MHz, as well as 4 analogue and 16 digital channels.

Features

Available bandwidths: 350 MHz, 200 MHz and 100 MHz
Real-time sampling rate of up to 2 GSa / s. For 350 MHz models an upgrade option for 500 MHz bandwidth is available.
SPO technology
Signal acquisition rates up to 120,000 wfm / s (normal mode) and 500,000 wfm / s (sequence mode)
Supports intensity gradation and colour temperature display modes with 256 levels
Recording length up to 200 Mpts / channel, 400 Mpts in total for all 4 channels
Digital trigger system
Intelligent trigger: Edge, Slope, Pulse, Window, Runt, Interval, Failure, Pattern and Video (HDTV supported). The trigger zone simplifies advanced triggering
Serial bus trigger and decoder, supports I 2 C, SPI, UART, CAN, LIN (standard) and CAN FD, FlexRay, I 2 S and MIL-STD-1553B (optional) protocols
Low background noise with voltage scales from 0.5 mV / div to 10 V / div
10-bit mode offers higher resolution and lower noise
Segmented acquisition mode (sequence mode) in which the maximum record length is divided into multiple segments (up to 90,000) according to the trigger conditions set by the user, with a very short dead time between segments for acquisition of the qualifying event
History waveform recording function (history) for up to 90,000 triggered waveforms (frames)
Automatic measurement function for more than 50 parameters, supports statistics with histogram and trend
Two mathematical traces support 2 Mpts FFT, +, -, x, ÷, d / dt, ∫dt, √, average, ERES and formula editor
Numerous data processing and analysis functions such as search, navigate, mask test, Bode plot, power analysis (optional) and counters
16 digital channels (optional)
Built-in 50 MHz waveform generator (optional)
Large 10.1-inch TFT LCD display with a resolution of 1024 × 600; the capacitive touchscreen supports multi-touch gestures
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11 / Telnet / Socket), Pass / Fail, Trigger Out
The integrated web server supports remote control via the LAN port using a web browser. Supports SCPI remote control commands

€1,199.00*

SDS2204X Plus Oscilloscope

Product Nr.: SDS2204X Plus

The SDS2204X Plus oscilloscope from Siglent offers a bandwidth of 200 MHz, as well as 4 analog and 16 digital channels.

Features

Available bandwidths: 350 MHz, 200 MHz and 100 MHz
Real-time sampling rate of up to 2 GSa / s. A 500 MHz bandwidth upgrade option is available for 350 MHz models.
SPO technology
Signal acquisition rates up to 120,000 wfm / s (normal mode) and 500,000 wfm / s (sequence mode)
Supports intensity gradation and color temperature display modes with 256 levels
Recording length up to 200 Mpts / channel, total 400 Mpts for all 4 channels
Digital trigger system
Intelligent trigger: edge, slope, pulse, window, runt, interval, failure, pattern and video (HDTV supported). Trigger zone simplifies advanced triggering
Serial bus triggering and decoder, supports I 2 C, SPI, UART, CAN, LIN (standard) and CAN FD, FlexRay, I 2 S and MIL-STD-1553B protocols (optional)
Low background noise with voltage scales from 0.5 mV / div to 10 V / div
10-bit mode provides higher resolution and lower noise
Segmented acquisition mode (sequence mode) where the maximum record length is divided into multiple segments (up to 90,000) according to user-specified trigger conditions, with a very short dead time between segments for acquisition of the qualifying event
History waveform recording function (history) for up to 90,000 triggered waveforms (frames)
Automatic measurement function for more than 50 parameters, supports statistics with histogram and trend
Two math tracks support 2 Mpts FFT, +, -, x, ÷, d / dt, ∫dt, √, average, ERES and formula editor
Numerous data processing and analysis functions such as search, navigate, mask test, Bode plot, power analysis (optional), and counter
16 digital channels (optional)
Built-in 50 MHz waveform generator (optional)
Large 10.1-inch TFT LCD display with 1024 × 600 resolution; capacitive touchscreen supports multi-touch gestures
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11 / Telnet / Socket), Pass / Fail, Trigger Out
Built-in web server supports remote control via LAN port using a web browser. Supports SCPI remote control commands

€1,899.00*

SDS2354X Plus Oscilloscope

Product Nr.: SDS2354X Plus

The SDS2354X Plus oscilloscope from Siglent offers a bandwidth of 350 MHz, as well as 4 analog and 16 digital channels.

Features

Available bandwidths: 350 MHz, 200 MHz and 100 MHz
Real-time sampling rate of up to 2 GSa / s. A 500 MHz bandwidth upgrade option is available for 350 MHz models.
SPO technology
Signal acquisition rates up to 120,000 wfm / s (normal mode) and 500,000 wfm / s (sequence mode)
Supports intensity gradation and color temperature display modes with 256 levels
Recording length up to 200 Mpts / channel, total 400 Mpts for all 4 channels
Digital trigger system
Intelligent trigger: edge, slope, pulse, window, runt, interval, failure, pattern and video (HDTV supported). Trigger zone simplifies advanced triggering
Serial bus triggering and decoder, supports I 2 C, SPI, UART, CAN, LIN (standard) and CAN FD, FlexRay, I 2 S and MIL-STD-1553B protocols (optional)
Low background noise with voltage scales from 0.5 mV / div to 10 V / div
10-bit mode provides higher resolution and lower noise
Segmented acquisition mode (sequence mode) where the maximum record length is divided into multiple segments (up to 90,000) according to user-specified trigger conditions, with a very short dead time between segments for acquisition of the qualifying event
History waveform recording function (history) for up to 90,000 triggered waveforms (frames)
Automatic measurement function for more than 50 parameters, supports statistics with histogram and trend
Two math tracks support 2 Mpts FFT, +, -, x, ÷, d / dt, ∫dt, √, average, ERES and formula editor
Numerous data processing and analysis functions such as search, navigate, mask test, Bode plot, power analysis (optional), and counter
16 digital channels (optional)
Built-in 50 MHz waveform generator (optional)
Large 10.1-inch TFT LCD display with 1024 × 600 resolution; capacitive touchscreen supports multi-touch gestures
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11 / Telnet / Socket), Pass / Fail, Trigger Out
Built-in web server supports remote control via LAN port using a web browser. Supports SCPI remote control commands

€2,599.00*

Details

SDS2104X HD Oscilloscope

Product Nr.: SDS2104X HD

The Siglent SDS2104X HD offers a bandwidth of 100 MHz. The oscilloscope has 4 analog and 16 digital channels.

Features

12-bit analog-to-digital converter with a sampling rate of up to 2 GSa/s
Front-end with 70 μVrms noise floor at 500 MHz bandwidth and 0.5% DC gain accuracy
4 analog channels, up to 350 MHz bandwidth (upgradeable up to 500 MHz)
SPO technology
Waveform acquisition rate up to 100,000 wfm/s (normal mode) and 500,000 wfm/s (sequence mode)
Supports 256-level intensity gradation and color temperature display modes
Recording length of up to 200 Mpts/channel
16 digital channels (optional)
Built-in 25 MHz waveform generator
Large 10.1" TFT LCD display with 1024 * 600 resolution; capacitive touch screen supports multi-touch gestures
Interfaces include: USB hosts, USB device (USBTMC), LAN (VXI-11/Telnet/Socket), Pass/Fail, Trigger Out.
Built-in web server supports remote control via LAN port with web browser
Supports SCPI remote control commands. Supports external mouse and keyboard

Product is discontinued

SDS2204X HD Oszilloskop

Product Nr.: SDS2204X HD

The Siglent SDS2204X HD offers a bandwidth of 200 MHz. The oscilloscope has 4 analog and 16 digital channels.

Features

12-bit analog-to-digital converter with a sampling rate of up to 2 GSa/s
Front-end with 70 μVrms noise floor at 500 MHz bandwidth and 0.5% DC gain accuracy
4 analog channels, up to 350 MHz bandwidth (upgradeable up to 500 MHz)
SPO technology
Waveform acquisition rate up to 100,000 wfm/s (normal mode) and 500,000 wfm/s (sequence mode)
Supports 256-level intensity gradation and color temperature display modes
Recording length of up to 200 Mpts/channel
16 digital channels (optional)
Built-in 25 MHz waveform generator
Large 10.1" TFT LCD display with 1024 * 600 resolution; capacitive touch screen supports multi-touch gestures
Interfaces include: USB hosts, USB device (USBTMC), LAN (VXI-11/Telnet/Socket), Pass/Fail, Trigger Out.
Built-in web server supports remote control via LAN port using a web browser. Supports SCPI remote control commands. Supports external mouse and keyboard

€2,280.00*

SDS2354X HD Oscilloscope

Product Nr.: SDS2354X HD

The Siglent SDS2354X HD offers a bandwidth of 350 MHz. The oscilloscope has 4 analog and 16 digital channels.

Features

12-bit analog-to-digital converter with a sampling rate of up to 2 GSa/s
Front-end with 70 μVrms noise floor at 500 MHz bandwidth and 0.5% DC gain accuracy
4 analog channels, up to 350 MHz bandwidth (upgradeable to 500 MHz)
SPO technology
Waveform acquisition rate up to 100,000 wfm/s (normal mode) and 500,000 wfm/s (sequence mode)
Supports 256-level intensity gradation and color temperature display modes
Recording length of up to 200 Mpts/channel
16 digital channels (optional)
Built-in 25 MHz waveform generator
Large 10.1" TFT LCD display with 1024 * 600 resolution; capacitive touch screen supports multi-touch gestures
Interfaces include: USB hosts, USB device (USBTMC), LAN (VXI-11/Telnet/Socket), Pass/Fail, Trigger Out.
Built-in web server supports remote control via LAN port using a web browser. Supports SCPI remote control commands. Supports external mouse and keyboard

€2,880.00*

SDS5034X Oscilloscope

Product Nr.: SDS5034X

The SDS5034X oscilloscope from Siglent has a bandwidth of 350 MHz, as well as 4 analog channels

Features

Model with 350 MHz with real-time sampling rate of up to 5 GSa / s
4 channels + EXT
SPO technology
Signal acquisition rates up to 110,000 Wfm / s (normal mode) and 480,000 Wfm / s (sequence mode)
Supports 256 intensity levels and color temperature display modes
Record length up to 250 Mpts
Digital trigger system
Intelligent trigger: Edge, Slope, Pulse, Window, Runt, Interval, Dropout, Pattern, Qualified and Video (HDTV supported). Trigger zone simplifies advanced triggering
Serial bus triggering and decoder, supports I2C, SPI, UART, CAN, LIN, CAN FD, FlexRay, I2S and MIL-STD-1553B protocols
Low background noise, supports voltage scales from 0.5 mV / div to 10 V / div
Segmented acquisition mode (sequence), which divides the maximum record length into multiple segments (up to 100,000) according to user-specified trigger conditions with a very short dead time between segments to capture the qualification event
History waveform record (history) function, the maximum length of the recorded signal waveform is 100,000 frames
Automatic measurement function for 39 parameters, supports statistics with histogram, gating measurement, math measurement, history measurement and ref measurement
25 MHz function / arbitrary signal generator, built-in multiple predefined signal waveforms
Large 10.1-inch TFT LCD display with a resolution of 1024 * 600; The capacitive touch screen supports multi-touch gestures
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11, Telnet, jack, web), pass / fail, trigger out, 10 MHz in, 10 MHz out, VGA output.
Built-in web server supports remote control via LAN port using web browser
Supports SCPI remote control commands

€2,869.00*

SDS5054X Oscilloscope

Product Nr.: SDS5054X

The SDS5054X oscilloscope from Siglent has a bandwidth of 500 MHz, as well as 4 analog channels

Features

Model 500 MHz with real-time sampling rate up to 5 GSa / s
4 channels + EXT
SPO technology
Signal acquisition rates up to 110,000 Wfm / s (normal mode) and 480,000 Wfm / s (sequence mode)
Supports 256 intensity levels and color temperature display modes
Record length up to 250 Mpts
Digital trigger system
Intelligent trigger: Edge, Slope, Pulse, Window, Runt, Interval, Dropout, Pattern, Qualified and Video (HDTV supported). The trigger zone simplifies advanced triggering
Serial bus triggering and decoder, supports I2C, SPI, UART, CAN, LIN, CAN FD, FlexRay, I2S and MIL-STD-1553B protocols
Low background noise, supports voltage scales from 0.5 mV / div to 10 V / div
Segmented acquisition mode (sequence), which divides the maximum record length into multiple segments (up to 100,000) according to user-specified trigger conditions with a very short dead time between segments to capture the qualification event
History waveform record (history) function, the maximum length of the recorded signal waveform is 100,000 frames
Automatic measurement function for 39 parameters, supports statistics with histogram, gating measurement, math measurement, history measurement, and ref measurement
25 MHz function / arbitrary signal generator, built-in multiple predefined signal waveforms
Large 10.1-inch TFT LCD display with a resolution of 1024 * 600; The capacitive touch screen supports multi-touch gestures
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11, Telnet, jack, web), pass / fail, trigger out, 10 MHz in, 10 MHz out, VGA output.
Built-in web server supports remote control via LAN port using web browser
Supports SCPI remote control commands

€4,959.00*

SDS5104X Oscilloscope

Product Nr.: SDS5104X

The SDS5104X oscilloscope from Siglent has a bandwidth of 1 GHz, as well as 4 analog channels

Features

Models with 1 GHz, 500 MHz and 350 MHz with real-time sampling rate up to 5 GSa / s
4 channels + EXT
SPO technology
Signal acquisition rates up to 110,000 Wfm / s (normal mode) and 480,000 Wfm / s (sequence mode)
Supports 256 intensity levels and color temperature display modes
Record length up to 250 Mpts
Digital trigger system
Intelligent trigger: Edge, Slope, Pulse, Window, Runt, Interval, Dropout, Pattern, Qualified and Video (HDTV supported). Trigger zone simplifies advanced triggering
Serial bus triggering and decoder, supports I2C, SPI, UART, CAN, LIN, CAN FD, FlexRay, I2S and MIL-STD-1553B protocols
Low background noise, supports voltage scales from 0.5 mV / div to 10 V / div
Segmented acquisition mode (sequence), which divides the maximum record length into multiple segments (up to 100,000) according to user-specified trigger conditions with a very short dead time between segments to capture the qualification event
History waveform record (history) function, the maximum length of the recorded signal waveform is 100,000 frames
Automatic measurement function for 39 parameters, supports statistics with histogram, gating measurement, math measurement, history measurement and ref measurement
25 MHz function / arbitrary signal generator, built-in multiple predefined signal waveforms
Large 10.1-inch TFT LCD display with a resolution of 1024 * 600; The capacitive touch screen supports multi-touch gestures
Multiple interfaces: USB host, USB device (USBTMC), LAN (VXI-11, Telnet, jack, web), pass / fail, trigger out, 10 MHz in, 10 MHz out, VGA output.
Built-in web server supports remote control via LAN port using web browser
Supports SCPI remote control commands

€6,359.00*

SDS6054A Digital Oscilloscope

Product Nr.: SDS6054A

The Siglent SDS6054A oscilloscope has a bandwidth of 500 Mhz, as well as 4 analogue and 16 digital channels.

Features

4 analogue channels, 500 MHz bandwidth with 5 GSa/s (10 GSa/s ESR) sampling rate on each channel
Low noise, supports vertical scales from 0.5 mV/div to 10 V/div
SPO technology
Waveform capture rates of up to 170,000 wfm/s (normal mode) and 750,000 wfm/s (sequence mode)
Supports 256-step intensity levels and colour temperature display modes
500 Mpts total signal recording length for all 4 channels
High-speed hardware-based averaging, hi-res; high-speed hardware-based mask test function, with mask editor for creating customised masks
16 digital channels (optional)
25 MHz arbitrary waveform generator, multiple predefined waveforms
Large 12.1" TFT LCD display with 1280 * 800 resolution; capacitive touchscreen that supports multi-touch gestures
Interfaces: USB hosts, USB device (USBTMC), LAN (VXI-11 / Telnet / Socket), Micro SD card, Pass / Fail, Trigger Out, HDMI

€6,480.00*
