With the MDO3504, Micsig presents its first desktop oscilloscope. Like the well-known tablet oscilloscopes, the device has a high-performance chip on which the in-house Android firmware Sigtest runs.
The high-resolution oscilloscope of the MDO series has a bandwidth of 350 MHz, a sampling rate of 3 GSa/s, 4 analogue channels, a memory depth of 360 Mpts and a vertical resolution of 12 bits. The housing thickness of only 4 cm, which is unusual for an oscilloscope, saves space and enables a very low weight.
The integrated 14-inch touch screen with a resolution of 1920 x 1200 and the 12-bit A/D converter provide a detailed waveform display.
Micsig offers a wide range of probes, take a look at the probes section.
The oscilloscope features the original Mic-OPI™ probe interface, which automatically recognises probes and enables one-button calibration. The device also has a variety of interfaces, such as USB 3.0 host, USB Type-C, LAN, HDMI, trigger output, etc.
Thanks to the digital trigger system, trigger jitter is very low and triggering is highly precise. In addition, the oscilloscope supports serial bus triggers and bus decoding of RS-232/422/485/UART, CAN, CAN FD, LIN, SPI, I²C, ARINC-429, MIL-STD1553B ex works.
Features
- Compact oscilloscope with 4 channels
- Bandwidth 350 MHz
- 3 GS/s real-time sampling rate.
- Android operating system
- Up to 360 Mpts memory depth.
- 14 inch LCD, resolution 1920x1080, capacitive multi-point touchscreen.
- Interfaces: Wi-Fi, USB 3.0/2.0 host, USB Type-C, HDMI, trigger out, grounding
- Connection for probe calibration.
- Supports bus trigger and decoding: RS-232/422/485/UART, CAN, CAN FD, LIN, SPI, I²C, ARINC-429, MIL-STD1553B.
- PC software, mobile iOS and Android app for remote control of the oscilloscope.
- Built-in 32GB memory for waveform and video recording.
- Screen sharing via WLAN, USB and HDMI
Oscilloscope features
User friendly
Equipped with the device-specific SigTestUI™ operating system and the accumulated 10 years of experience in UI design, the MDO series has been further developed to simplify all user interfaces so that newer engineers can quickly learn to use it in 5 minutes.
Very low noise floor
The noise of the MDO series is less than 90 μVrms at full bandwidth of 500 MHz, allowing engineers to accurately capture weak but important signals during circuit debugging.
Hardware Digital Filter
Hardware digital filtering can selectively pass or block signal components within a specific frequency range, which is very useful for analysing specific frequency bands of a signal or observing changes in specific frequency components.
360 Mpts memory depth
A memory depth of up to 360 Mpts ensures excellent signal fidelity, the segmented memory divides the limited memory space into several small segments, effectively capturing target signals multiple times over a long period of time and replaying them for further analysis.
Many trigger functions
Serial bus decoding & trigger
Supports serial triggering and decoding (RS-232/422/485/UART, CAN, CAN FD, LIN, SPI, I²C, ARINC-429, MIL-STD1553B) as well as edge, pulse, logic, time out, Dwart PW, slope, N edge and video trigger.
Automatic measurements
31 automatic measurements for a wide range of measurement requirements.
Screen sharing function
the screen content of the oscilloscope can be easily streamed to an external monitor via the built-in HDMI connection.
Technical Data
| Model |  MDO5004 | MDO3504 | MDO2504 |
|---|---|---|---|
| Bandwidth | 500 MHz | 350 MHz | 250 MHz |
| Rise time | ≤0.7 ns | ≤1ns | ≤1.4 ns |
| Analogue channels | 4 | 4 | 4 |
| Real-time sampling rate | 3GSa/s | 3GSa/s | 3GSa/s |
| Memory depth | 360 Mpts | 360 Mpts | 360 Mpts |
| Max. Waveform capture rate | 230.000 Wfms/s | 230.000 Wfms/s | 230.000 Wfms/s |
| Noise | <90µVrms | <90µVrms | <90µVrms |
| Interfaces | USB 3.0 host, USB Type-C, HDMI, trigger output | USB 3.0 host, USB Type-C, HDMI, trigger output | USB 3.0 host, USB Type-C, HDMI, trigger output |
| Display | 14" full-touch display, resolution 1920 x 1200 | 14" full-touch display, resolution 1920 x 1200 | 14" full-touch display, resolution 1920 x 1200 |
| Dimensions/net weight | 400*280*35.8 mm / 4.3 kg | 400*280*35.8 mm / 4.3 kg | 400*280*35.8 mm / 4.3 kg |
