RCP300XS-200 Rogowski coil current probe
Recommended addition
CP6500
Rogowski current probe RCP300XS-200 for precise AC current measurements up to 60 Apk, 300 MHz bandwidth, 1.6 mm coil - ideal for MOSFET & pin measurements.
Volume discounts on request!
€1,049.00 Net
€1,248.31 incl. VAT
Shipping country
Customer Group
Währung
Delivery time: 3-4 weeks
Content: 1
.jpg){kind=icon}
.jpg){kind=icon}
.jpg)
.jpg)
.jpg)
.jpg)
- 1 year guarantee
- 2.5% advance payment discount
- If you use the payment method in advance by bank transfer, 2.5% of the purchase amount will be automatically deducted at the checkout.
Free shipping
Good / Better / Best setups
Quickly build a complete measurement setup.
Professional Setup
Anwendungsbezogene Kombination aus Zubehör, Software und Service.
Main product
RCP300XS-200 Rogowski coil current probe
Recommended addition
CP6500
Recommended addition
SCP5500
Recommended addition
MHO68-10001
Recommended addition
CP6150
3% bundle benefit is calculated in cart.
Komplett-Setup
Umfangreicheres Setup mit passenden Ergänzungen und Absicherung.
Main product
RCP300XS-200 Rogowski coil current probe
Recommended addition
CP6500
Recommended addition
SCP5500
Recommended addition
MHO68-10001
Recommended addition
CP6150
Recommended addition
SCP5150
Recommended addition
CP6030A
5% bundle benefit is calculated in cart.
Description
The RCP series from Micsig are Rogowski coil probes which can measure AC currents and high frequency, large current signals up to 12000 Apk (model dependent). The RCP probes have a wide bandwidth in the MHz range (model dependent) with typical accuracy down to 1% and less than 18mv noise.
The RCP is characterised by outstanding performance and exquisite design. A thin, flexible Rogowski coil with clip allows the user to perform measurements without damaging the conductor or disturbing the device under test. For example, the flexible loop can be easily wrapped around a cable, allowing measurements to be taken in hard-to-reach places. Wire length and coil size can be customised, offering different choices for your daily design and troubleshooting.
Main features
- Bandwidth:
- RCP-XS =85 Hz - 30 MHz | RCP-S=14 Hz - 25 MHz | RCP-M=14 Hz - 25 MHz | RCP-L=8 Hz - 10 MHz
- Coil cross-section (diameter): RCP-XS =1.6mm | RCP-S=3mm | RCP-M =4.5mm | RCP-L=8mm
- Accuracy (typical): 2 %
- Cable length 1.5m
- Terminating resistor: 1MΩ
- BNC connection: Can be used with any oscilloscope regardless of manufacturer
Further functions
Measure the ID current of the MOSFET
The RCP series probes have excellent high-frequency measurement capabilities, easily handle high-speed signals and rapidly changing current waveforms, and help observe high-frequency harmonic components when measuring the ID current of MOSFETs.
BNC interface
The RCP Rogowski series has a standard BNC interface making it compatible with any oscilloscope from any manufacturer.
Different coil cross-sections
The cross-sectional diameter of the smallest coil is only 1.6 mm, allowing engineers to measure the current on the hard-to-reach parts of the circuit, for example on chips with narrow pin spacing such as TO-220, TO-47.
Applications
- Measurement of current with a mains frequency of 50/60 Hz
- Measurement of harmonic components in the current
- Measurement of pin currents in MOSFET or IGBT devices
- Measurement of load currents and higher-order harmonic currents in power electronics
- Measurement of current in motor drives and for power quality (VSD, UPS, SMPS)
- Double-pulse tests for pin currents in SiC and GaN semiconductors
Technical Data
| Parameters | RCP-XS Series | RCP-S Series | RCP-M Series | RCP-L series |
|---|---|---|---|---|
| Typical coil cross-section | 1.6 mm | 3.0 mm | 4.5 mm | 8.0 mm |
| Available spool circumferences | 80 mm, 200 mm | 200 mm, 700 mm | 200 mm, 700 mm | 700 mm |
| Measurable conductor diameter | ≤ 20 mm / ≤ 60 mm | ≤ 60 mm / ≤ 220 mm | ≤ 60 mm / ≤ 220 mm | ≤ 220 mm |
| Max. Bandwidth | 30 MHz | 25 MHz | 25 MHz | 10 MHz |
| Measuring range (peak current) | 60 Apk - 12,000 Apk | 120 Apk - 12,000 Apk | 120 Apk - 12,000 Apk | 600 Apk - 12,000 Apk |
| Typical accuracy | 2 % | 2 % | 2 % | 2 % |
| Max. Coil insulation voltage | 1.5 kVpk | 3 kVpk | 5 kVpk | 10 kVpk |
| Typical applications | Pin-level measurements, MOSFET / IGBT, SiC / GaN, very tight installation spaces | Power electronics, SMPS, inverters, Development & diagnostics | Industrial applications, higher voltages, robust measurements | High current & high voltage, Motors, energy, Grid & industrial applications |
RCP-L series (typical coil cross-section diameter: 8.0 mm)
| Model | Bandwidth | Peak current | Output sensitivity | Output noise | Max. di/dt | Droop (%/ms) | Output accuracy | Max. Coil insulation voltage | Coil circumference |
|---|---|---|---|---|---|---|---|---|---|
| RCP600L-700 | 8 Hz - 10 MHz | 600 Apk | 10 mV/A (100×) | <18 mVpp | 70 kA/µs | 8 | 2 % | 10 kVpk | 700 mm |
| RCP1200L-700 | 6 Hz - 10 MHz | 1200 Apk | 5 mV/A (200×) | <12 mVpp | 70 kA/µs | 5 | 2 % | 10 kVpk | 700 mm |
| RCP3000L-700 | 4 Hz - 10 MHz | 3000 Apk | 2 mV/A (500×) | <9 mVpp | 70 kA/µs | 2 | 2 % | 10 kVpk | 700 mm |
| RCP6000L-700 | 3 Hz - 10 MHz | 6000 Apk | 1 mV/A (1000×) | <6 mVpp | 70 kA/µs | 2 | 2 % | 10 kVpk | 700 mm |
| RCP12000L-700 | 2 Hz - 10 MHz | 12000 Apk | 0.5 mV/A (2000×) | <5 mVpp | 70 kA/µs | 2 | 2 % | 10 kVpk | 700 mm |
RCP-M series (typical coil cross-section diameter: 4.5 mm)
| Model | Bandwidth | Peak current | Output sensitivity | Output noise | Max. di/dt | Droop (%/ms) | Output accuracy | Max. Coil insulation voltage | Coil circumference |
|---|---|---|---|---|---|---|---|---|---|
| RCP120M-200 | 14 Hz - 25 MHz | 120 Apk | 50 mV/A (20×) | <25 mVpp | 8 kA/µs | 18 | 2 % | 5 kVpk | 200 mm |
| RCP300M-200 | 7 Hz - 25 MHz | 300 Apk | 20 mV/A (50×) | <20 mVpp | 20 kA/µs | 8 | 2 % | 5 kVpk | 200 mm |
| RCP600M-200 | 5 Hz - 25 MHz | 600 Apk | 10 mV/A (100×) | <18 mVpp | 40 kA/µs | 5 | 2 % | 5 kVpk | 200 mm |
| RCP1200M-200 | 5 Hz - 25 MHz | 1200 Apk | 5 mV/A (200×) | <7 mVpp | 70 kA/µs | 5 | 2 % | 5 kVpk | 200 mm |
| RCP3000M-200 | 3 Hz - 25 MHz | 3000 Apk | 2 mV/A (500×) | <7 mVpp | 70 kA/µs | 2 | 2 % | 5 kVpk | 200 mm |
| RCP6000M-200 | 2 Hz - 25 MHz | 6000 Apk | 1 mV/A (1000×) | <5 mVpp | 70 kA/µs | 2 | 2 % | 5 kVpk | 200 mm |
| RCP6000M-700 | 3 Hz - 10 MHz | 6000 Apk | 1 mV/A (1000×) | <6 mVpp | 70 kA/µs | 3 | 2 % | 5 kVpk | 700 mm |
| RCP12000M-700 | 2 Hz - 10 MHz | 12000 Apk | 0.5 mV/A (2000×) | <5 mVpp | 70 kA/µs | 2 | 2 % | 5 kVpk | 700 mm |
RCP-S series (typical coil cross-section diameter: 3.0 mm)
| Model | Strip width | Peak current | Output sensitivity | Output noise | Max. di/dt | Droop (%/ms) | Output accuracy | Max. Coil insulation voltage | Coil circumference |
|---|---|---|---|---|---|---|---|---|---|
| RCP120S-200 | 14 Hz - 25 MHz | 120 Apk | 50 mV/A (20×) | <25 mVpp | 8 kA/µs | 18 | 2 % | 3 kVpk | 200 mm |
| RCP300S-200 | 7 Hz - 25 MHz | 300 Apk | 20 mV/A (50×) | <20 mVpp | 20 kA/µs | 8 | 2 % | 3 kVpk | 200 mm |
| RCP600S-200 | 5 Hz - 25 MHz | 600 Apk | 10 mV/A (100×) | <18 mVpp | 40 kA/µs | 5 | 2 % | 3 kVpk | 200 mm |
| RCP1200S-200 | 5 Hz - 25 MHz | 1200 Apk | 5 mV/A (200×) | <7 mVpp | 70 kA/µs | 5 | 2 % | 3 kVpk | 200 mm |
| RCP3000S-200 | 3 Hz - 25 MHz | 3000 Apk | 2 mV/A (500×) | <7 mVpp | 70 kA/µs | 2 | 2 % | 3 kVpk | 200 mm |
| RCP6000S-200 | 2 Hz - 25 MHz | 6000 Apk | 1 mV/A (1000×) | <5 mVpp | 70 kA/µs | 2 | 2 % | 3 kVpk | 200 mm |
| RCP6000S-700 | 3 Hz - 10 MHz | 6000 Apk | 1 mV/A (1000×) | <6 mVpp | 70 kA/µs | 3 | 2 % | 3 kVpk | 700 mm |
| RCP12000S-700 | 2 Hz - 10 MHz | 12000 Apk | 0.5 mV/A (2000×) | <5 mVpp | 70 kA/µs | 2 | 2 % | 3 kVpk | 700 mm |
RCP-XS series (typical coil cross-section diameter: 1.6 mm)
| Model | Bandwidth | Peak current | Output sensitivity | Output noise | Max. di/dt | Droop (%/ms) | Output accuracy | Max. Coil insulation voltage | Coil circumference |
|---|---|---|---|---|---|---|---|---|---|
| RCP60XS-80 | 70 Hz - 30 MHz | 60 Apk | 100 mV/A (10×) | <25 mVpp | 4 kA/µs | 65 | 2 % | 1.5 kVpk | 80 mm |
| RCP120XS-80 | 34 Hz - 30 MHz | 120 Apk | 50 mV/A (20×) | <25 mVpp | 8 kA/µs | 35 | 2 % | 1.5 kVpk | 80 mm |
| RCP300XS-80 | 10 Hz - 30 MHz | 300 Apk | 20 mV/A (50×) | <25 mVpp | 20 kA/µs | 9 | 2 % | 1.5 kVpk | 80 mm |
| RCP600XS-80 | 8 Hz - 30 MHz | 600 Apk | 10 mV/A (100×) | <18 mVpp | 40 kA/µs | 7 | 2 % | 1.5 kVpk | 80 mm |
| RCP1200XS-80 | 5 Hz - 30 MHz | 1200 Apk | 5 mV/A (200×) | <15 mVpp | 70 kA/µs | 3 | 2 % | 1.5 kVpk | 80 mm |
| RCP3000XS-80 | 4 Hz - 30 MHz | 3000 Apk | 2 mV/A (500×) | <8 mVpp | 70 kA/µs | 2 | 2 % | 1.5 kVpk | 80 mm |
| RCP6000XS-80 | 4 Hz - 30 MHz | 6000 Apk | 1 mV/A (1000×) | <5 mVpp | 70 kA/µs | 2 | 2 % | 1.5 kVpk | 80 mm |
| RCP12000XS-80 | 2 Hz - 30 MHz | 12000 Apk | 0.5 mV/A (2000×) | <6 mVpp | 70 kA/µs | 2 | 2 % | 1.5 kVpk | 80 mm |
| RCP300XS-200 | 14 Hz - 20 MHz | 300 Apk | 20 mV/A (50×) | <20 mVpp | 20 kA/µs | 15 | 2 % | 1.5 kVpk | 200 mm |
| RCP600XS-200 | 7 Hz - 20 MHz | 600 Apk | 10 mV/A (100×) | <18 mVpp | 40 kA/µs | 7 | 2 % | 1.5 kVpk | 200 mm |
| RCP1200XS-200 | 5 Hz - 20 MHz | 1200 Apk | 5 mV/A (200×) | <15 mVpp | 70 kA/µs | 3 | 2 % | 1.5 kVpk | 200 mm |
| RCP6000XS-200 | 3 Hz - 20 MHz | 6000 Apk | 1 mV/A (1000×) | <7 mVpp | 70 kA/µs | 3 | 2 % | 1.5 kVpk | 200 mm |
