A2B Protocol Analysers & Bridges

Product Nr.: AKT-1000-A

Allows the emulation of A2B main or sub-nodes. Simple routing of any audio channels.

A2B main bus detection or sub-nodes via USB UAC 2.0
Bit Perfect Audio/A2B conversion via USB
Flexible routing of 32 inputs/32 outputs for audio channels via USB
Emulate A2B main node or sub-nodes
Full script launch - no PC required
Upgrade option for LUA scripting for autonomous start CMD/CTRL
Built-in signal generators and peak level detectors
Mailbox protocol support
Compatible with AD242X and AD243X
Future support for A2B 2.0 (AD245X)
QwiiC I2C interface for peripheral expansion (RTC, touch LCD)
Built-in command line and terminal emulator
Integration in Digital Audio Workstation (DAW) possible such as Audacity and Reaper

€899.00*

Product Nr.: AKT-1000-B

Allows the emulation of A2B main or sub-nodes. Simple routing of any audio channels.

A2B main bus detection or sub-nodes via USB UAC 2.0
Bit Perfect Audio/A2B conversion via USB
Flexible routing of 32 inputs/32 outputs for audio channels via USB
Emulate A2B main node or sub-nodes
Full script launch - no PC required
Upgrade option for LUA scripting for autonomous start CMD/CTRL
Built-in signal generators and peak level detectors
Mailbox protocol support
Compatible with AD242X and AD243X
Future support for A2B 2.0 (AD245X)
QwiiC I2C interface for peripheral expansion (RTC, touch LCD)
Built-in command line and terminal emulator
Integration in Digital Audio Workstation (DAW) possible such as Audacity and Reaper

€899.00*

Product Nr.: AKT-1500

The Flextech Bus Monitor allows you to capture A2B audio traffic as well as I2C and SPI in real time.

User-friendly PC interface via bit-accurate USB UAC 2.0
Set up for independent bus activity logging in the vehicle
Recording of all bus activities immediately upon detection and in continuous operation
Lua API for fully autonomous scripting and system startup
SD card for autonomous bus activity and data logging
AD242X and AD243X compatible (high voltage)
Flexible routing of A2B audio channels via USB/PC
Capture and easy readout of I2C and SPI data traffic
Small, lightweight, with status LEDs - fits in any pocket
QwiiC I2C interface for peripheral expansions (RTC, touch LCD)

€999.00*

Product Nr.: AKT-2000

USB interface and configuration of any TDM audio signals at chip level for transmission and reception tests.

Precise TDM/I2S signal configuration and alignment
Clock generation for low delay difference and jitter
Bit-accurate audio via TDM and USB
Supports 32 inputs and 32 outputs with up to 32-bit audio channels
Flexible real-time audio routing via USB, WAV and TDM
10 TDM inputs and outputs (5 pairs) for up to 160 16-bit channels
Integrated signal generators route to all TDM audio channels
Integrated VU meter
Compatible with ADI
A2B transceivers for bus configuration and detection
Micro SD card for TDM audio WAV file recording/playback or self-boot
Includes a flexible cable set kit for interfacing TDM inputs and outputs, I2C, SPI and GPIO signals

€683.00*
