- 2.5% advance payment discount
- If you use the payment method in advance by bank transfer, 2.5% of the purchase amount will be automatically deducted at the checkout.
- This product has been discontinued by the manufacturer
Product configuration
Description
The ATTEN GT-8100A soldering station is an intelligent digital soldering station with a 1300 W heating element for temperatures from 100 - 500 °C. The lightweight soldering iron is well suited for long periods of work at precise and stable temperatures.
Features
- Large TFT colour screen for convenient setting and monitoring of parameters.
- 1300 W plug-in ceramic heater for rapid heating.
- Built-in brushless fan for long service life and low noise levels.
- PID temperature control for precise and stable temperature.
- Infrared temperature calibration function.
- Temperature curve setting.
- 3 quick settings for air volume/temperature simplify operation.
- Switching the smoke purifier on and off.
- Control via external pedal.
- RS485 interface for IoT functions.
Hardware details
The Atten GT-8100A Rework Station has 1300 watts of power and is supplied with suitable PC software for control. The GT-8100A is equipped with a user-friendly colour display with which the most important functions can be accessed via intuitive menu navigation. The soldering station automatically lowers the temperature to 100°C when not in use. Three different temperatures can be easily programmed individually and can be called up directly by pressing the corresponding selection button.
The rework station has a temperature stability of 1°C and enables precise reworking.
Included nozzles
Technical Data
| Model | GT-8100A |
|---|---|
| Power output | 1330 watts |
| Temperature range | 100°C - 480°C |
| Temperature offset range | ±50°C |
| Temperature setting | 5 digits (standard) / 1 digit (fine-tuning) |
| Temperature stability | 1°C |
| Volume flow (air) | 120 litres / min |
| ESD protection | ✓ |
| Earthing resistance | < 2 Ohm |
| Earth potential | < 2 mV |
| Weight | 8.1 kg |
| Power supply | 230 V / 50 Hz |
| RoHS | Compliant |
