ATTEN ST-7500 is an intelligent 400W preheating platform with precise PID temperature control for efficient rework and soldering processes.
Product is discontinued
- 2.5% advance payment discount
- If you use the payment method in advance by bank transfer, 2.5% of the purchase amount will be automatically deducted at the checkout.
In Stock, Delivery time: 1 - 3 days
Further information
.jpg){kind=icon}
.jpg){kind=icon}
.jpg)
.jpg)
.jpg)
.jpg)
Product number: ST-7500
Manufacturer: Atten
- This product has been discontinued by the manufacturer
Description
The ATTEN ST-7500 is a thermal preheating or reflow platform for the gentle heating of PCBs before soldering or desoldering.
This platform is used in particular in electronics repair and production to minimise the risk of component damage due to thermal shock. By preheating the board evenly, soldering work can be carried out more efficiently and safely - for example during BGA/SMD repairs or when removing heat-sensitive components.
The ST-7500 has an antistatic design, three quickly selectable temperature settings, a temperature lock and precise PID control in the range from 50 °C to 500 °C, making it ideal for professional rework applications.
Features
- Antistatic design
- Three quick parameter sets for fast temperature changeover
- Temperature interlock and temperature compensation for constant temperature operation.
- PLD control with closed sensor circuit for precise and stable temperature.
- Suitable for preheating PCBs and other processes that require uniform heating.
- Equipped with an external K-type sensor interface for practical verification of the actual temperature of heating products.
Technical Data
| Model | ST-7500 | ST-7800 |
|---|---|---|
| Model | ST-7500 | ST-7800 |
| Voltage | AC 220-240V~50/60Hz（AC 110-120V~60Hz） | AC 220-240V~50/60Hz（AC 110-120V~60Hz） |
| Power output | 400W (±10%) | 800W (±10%) |
| Temperature range | 50°C ~ 500°C | 50°C ~ 350°C |
| Heating surface | 120 × 120 mm | 200 × 180 mm |
| Heating material | Infrared ceramic | Aluminium plate |
| External thermocouple input (type K) | Supported (0~650 °C measuring range) | Supported (0~650 °C measuring range) |
| Communication function | Supported (RS485 interface) | Supported (RS485 interface) |
| Link function | Supported (e.g. with ATTEN fume extraction) | Supported (e.g. with ATTEN smoke extraction system) |
| Temperature lock | Supported | Supported |
| Dimensions | 278 × 203 × 73 mm | 355 × 293 × 73 mm |
| Weight (device) | ≈2.4 kg | ≈5.1 kg |
| Standard packaging | Inner carton: 353 × 353 × 140 mm Gross weight: ≈3 kg Outer carton: 4 pieces/carton Size: 368 × 368 × 585 mm Gross weight: ≈13 kg | Inner carton: 465 × 402 × 200 mm Gross weight: ≈6.5 kg Outer carton: 2 pieces/carton Size: 482 × 418 × 430 mm Gross weight: ≈14 kg |
