Comprehensive testing of vehicle engines
The reliability and safety of vehicle engines are crucial factors that automotive manufacturers prioritize. Therefore, the corresponding verification of the engine's performance , as well as insulation and dielectric strength testing, are essential steps in the development and production process.
Solution details
Number of tests:
2 exams
Exam content:
- Dielectric strength test
- Insulation test
- Inductance measurement
- DC low-resistance measurement
- Inter-winding insulation test
- Detection of the contact status of the test device
- Kelvin measurement
Test requirements:
- Intermediate winding test: 500 V
- Insulation resistance: >100 MΩ
- AC voltage withstand: <0.5 mA
- Inductance: L=0.17 mH ±10 %
List of instruments
- 1 × TH9520A
