The Owon SPE3103 power supply delivers max. 300W at max. 30V / 10A and has one channel.
€90.00*
Content: 1
Volume discounts on request!
- 3-year guarantee
- 2.5% advance payment discount
- If you use the payment method in advance by bank transfer, 2.5% of the purchase amount will be automatically deducted at the checkout.
Free shipping
In Stock, Delivery time: 1 - 3 days
Further information
.jpg){kind=icon}
.jpg){kind=icon}
.jpg)
.jpg)
.jpg)
.jpg)
Product number: SPE3103
Description
The OWON SPE series comprises compact, programmable 1-channel DC laboratory power supplies with outputs from 150 W to 300 W. All models have a 2.8″ colour LCD, OVP/OCP protection functions, 4 memory locations (M1-M4) and a list mode for programmable output sequences.
The integrated USB charging function (QC2.0/3.0, BC1.2, FCP, AFC) with up to 12 W for mobile devices is particularly practical. The devices offer a resolution of 1 mV / 1 mA, enable very fine voltage and current settings and are therefore equally suitable for laboratory, development, service and training.
Features
- Ultra-thin housing, portable and easy to use
- 150W / 200W / 300W constant power design, wide application range
- overvoltage/overcurrent protection
- Automatic power adjustment function when switching on, suitable for unattended occasions
- Intelligent fan cooling with temperature control, reduces noise
- 4 groups of memory link parameters for fast output
- USB device communication port, supports SCPI
- Constant voltage CV/constant current CC mode, effectively protects the circuit
Technical Data
| Model |  SPE3051 | SPE3102 | SPE3103 | SPE6103 |
|---|---|---|---|---|
| Channels | 1 | 1 | 1 | 1 |
| Max. Output voltage | 30 V | 30 V | 30 V | 60 V |
| Max. Output current | 5 A | 10 A | 10 A | 10 A |
| Max. Max. power | 150 W | 200 W | 300 W | 300 W |
| Resolution | 1 mV / 1 mA | 1 mV / 1 mA | 1 mV / 1 mA | 1 mV / 1 mA |
| Display | 2.8″ colour LCD | 2.8″ Colour LCD | 2.8″ Colour LCD | 2.8″ Colour LCD |
| Protective functions | OVP, OCP | OVP, OCP | OVP, OCP | OVP, OCP |
| Quick memory | 4 (M1-M4) | 4 (M1-M4) | 4 (M1-M4) | 4 (M1-M4) |
| USB charging function | QC2.0/QC3.0/BC1.2/FCP/AFC, 12 W | QC2.0/QC3.0/BC1.2/FCP/AFC, 12 W | QC2.0/QC3.0/BC1.2/FCP/AFC, 12 W | QC2.0/QC3.0/BC1.2/FCP/AFC, 12 W |
