Prodigy's compact I3C/I2C USB adapter for analytics, traffic generation, and API automation. Supports 100 kHz–12.5 MHz and continuous recording.
Volume discounts on request!
€2,850.00 Net
€3,391.50 incl. VAT
Shipping country
Customer Group
Währung
In Stock, Delivery time: 1-3 days
.jpg){kind=icon}
.jpg){kind=icon}
.jpg)
.jpg)
.jpg)
.jpg)
Description
Productivity-oriented I3C/I2C adapter for protocol analysis and traffic generation. The adapter enables master and slave configurations, continuous recording of protocol data, and API-driven automation. Ideal for debugging, protocol analysis, and simple automation scripts.
Features
- Configurable as master or slave (1 master + 1 slave)
- Protocol support: I3C and I2C
- SCL frequency range 100 kHz to 12.5 MHz
- Fixed adjustable voltage levels: 1 V, 1.2 V, 1.8 V, 2.5 V, 3.3 V
- Exerciser functions: Traffic generation and simulation of real loads
- Analyzer resolution 4 ns
- Continuous streaming of captures to host drive
- API support for automation, programming access via Python
- Host connectivity via USB 2.0/3.0
The PGY-I3C_USB_Adapter is a compact, budget-friendly tool for analyzing and generating I3C and I2C communication. As a combined exerciser and analyzer, the device configurably supports one master and one slave, enables variable SCL frequencies from 100 kHz to 12.5 MHz, and operates with fixed voltage levels (1 V, 1.2 V, 1.8 V, 2.5 V, 3.3 V). The analysis function offers a resolution of 4 ns and allows continuous streaming of recorded data to a host drive for long-term recording. API interfaces for automated workflows are available; control is possible via Python, and there is support for Linux and Windows hosts. Typical use cases include protocol debugging, validation of master/slave implementations, and automated test scripts in development and production test scenarios. The device is positioned as an affordable alternative to higher-end models when basic exerciser and analyzer functionality along with API automation is required.
Technical Data
| Device specification | PGY-I3C_USB_Adapter |
|---|---|
| Product number | PGY-I3C_USB_Adapter |
| Supported protocols | I3C, I2C |
| Host interface | USB 2.0/3.0 |
| Exerciser configuration | 1 Master + 1 Slave |
| SCL frequency | 100 kHz – 12.5 MHz |
| Voltage level | 1V, 1.2V, 1.8V, 2.5V, 3.3V (fixed) |
| Analyzer resolution | 4 ns |
| Capture duration | Continuous streaming to host drive |
| API support | Python (supports Linux and Windows) |
