Siglent's PP215 is a passive probe with a bandwidth of 200 MHz.
Description
The PP215 probe is an attenuation oscilloscope probe with a bandwidth of 200 MHz.
Features
- Bandwidth: 200MHz
- 85/18pf
- 1X/10X Attenuation
- 1M/10Mohm
- 6M/200MHz
- 300V/600V
- Operating temperature -15 to 75 degrees
Technical Data
Specifications | CP4050 |
---|---|
Bandwidth | 1MHz |
Maximum Continuous Current | 50 Arms |
Peak Current | 140A |
Switching Ratio | 500mV/A; 5mV/A |
DC Measurement Accuracy | 500mV/A (20mA-14 Apk) ±3%±20mA; 50mV/A (200mA-100ApK) ±4% ±4% 200mA; 50mV/A (100A-140ApK)±15% |
Power | 9V battery |
Weight | 400 grams |
