€249.00 Net
€296.31 incl. VAT
Delivery time: 1-2 weeks
.jpg){kind=icon}
.jpg){kind=icon}
.jpg)
.jpg)
.jpg)
.jpg)
- 1 year guarantee
- 2.5% advance payment discount
- If you use the payment method in advance by bank transfer, 2.5% of the purchase amount will be automatically deducted at the checkout.
Description
The Micsig DP10007 is part of the new series of cost-effective differential probes from Micsig. With this probe you can use your conventional grounded oscilloscope to measure floating signals of up to 700 V differential and common mode voltage in 200:1 mode. This is particularly useful when developing power supplies, motor drivers and when working with electronic ballasts. Thanks to the probe's high dielectric strength, you can carry out measurements on the mains supply without damaging the oscilloscope.
The probe is simply supplied with power via USB, a common interface for all modern oscilloscopes and computers. This makes the probe a very portable tool and eliminates the need for a special adapter module.
Technical Data
| Model comparison | Bandwidth | Differential voltage (DC+AC PK) Max. | CMRR | Input impedance |
|---|---|---|---|---|
 DP10007/ DP700 | 100 MHz | 70V（20X） 700V（200X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
