Siglent SPD1305X DC Laboratory Power Supply

The SPD1305X is a DC laboratory power supply with an output power of max. 150 W.

€249.00*

  • 3 Years Warranty
  • 2.5% advance payment discount

Free shipping

Delivery time: 1 week

Further information
Model
Request a quote
Paypal-icon
Mastercard-icon
visa-icon
klarna-icon
Sepa-lastschrift-icon
invoice-icon
Product number: SPD1305X
Manufacturer: Siglent

Description

The SPD1305X programmable linear DC power supply features a 2.8-inch TFT LCD display, remote computer control function and real-time wave display to provide high performance and ease of use.

Features

  • High precision programmable single path voltage output:
  • SPD1068X: 16 V / 8 A, total power up to 128 W
  • SPD1305X: 30 V / 5 A, total power up to 150 W.
  • Stable, reliable, low ripple and noise: ≤ 350 uVrms/3 mVpp; < 2 mAeff.
  • Fast settling time: < 50 μs
  • 5-digit voltage, 4-digit current display, minimum resolution: 1 mV/1 mA
  • 2 types of output modes: two-wire output mode, 4-wire compensation output mode, maximum compensation voltage 1 V
  • Support timing output functions on front panel
  • 100/120/220/230 V compatible design to meet the requirements of different power networks
  • Intelligent temperature controlled fan reduces noise
  • Clear graphical user interface with the waveform display function
  • Internal 5 groups of system parameters can be stored/recalled
  • Includes PC software: Easypower, supports SCPI, LabView driver
SPD1305X - Front

Hardware details

The SPD1168 has a high-precision programmable output that can deliver up to 16 V, the SPD1305X has a high-precision programmable output that can deliver up to 30 V, and also includes a 4-wire detection function for more accurate voltage supply, especially for long lines or high-impedance connections. There are additional output short-circuit and overload protection features to support production and development applications.

Product highlights

Productvideo

SPD1305X - Introduction

Technical Data

Model comparisonSPD1168X - Small
SPD1168X
SPD1305X - Small
SPD1305X
Maximum output power128W150W
Channel OutputOutput voltage: 0 to 16 V Output current: 0 to 8 AOutput voltage: 0 to 30 V Output current: 0 to 5 A
Display2.8" true color TFT LCD with 5-digit voltage/4-digit current2.8" true color TFT LCD with 5-digit voltage/4-digit current
Resolution1mV/1mA1mV/1mA
Program AccuracyVoltage: ± (0.03% of reading + 10 mV) Current: ±; (0.3% of reading + 10mA)Voltage: ± (0.03% of reading + 10 mV) Current: ±; (0.3% of reading + 10mA)
Constant current modegrid regulation ? 0.2% + 3 mA
Load regulation ? 0.2% + 3mA
grid regulation ? 0.2% + 3 mA
Load regulation ? 0.2% + 3mA
Constant voltage modeload control ? 0.01% + 2 mV
Residual ripple and noise ? 350uVrms/3mVpp (20Hz to 20MHz)
Recovery time < 50 µs (50% load change, minimum load 0.5 A)
load control ? 0.01% + 2 mV
Residual ripple and noise ? 350uVrms/3mVpp (20Hz to 20MHz)
Recovery time < 50 µs (50% load change, minimum load 0.5 A)
Locking KeyYesYes
Power sourceAC 100/120/220/230V ± 10% 50/60HzAC 100/120/220/230V ± 10% 50/60Hz
