Description
The SSG5080A-F85 is a bandwidth upgrade from 13.6 GHz to 20 GHz for Sieglent's SSG5000A series.
Technical Data
Parameter | SMA-SMA-18L |
---|---|
Connector 1 | SMA |
Connector 2 | SMA |
Length | 1000 + 10 (mm) |
Insertion loss (DC - 18 GHz, dB) | (DC - 18 GHz, dB): 2.3 |
Impedance | 50 Ω |
Frequency | DC-18GHz |
VSWR | <1.25 to 18 GHz |
Phase stability vs. bending | <±10° at 18 GHz (wrapped around a mandrel with 50 mm diameter) |
