Description
The Siglent SPS5162X is a single channel programmable DC switching power supply that offers a range of 0-160V 0-15A with a maximum output power of 720W.
Features
- Rated output voltage 40V, 50V, 80V, 160V
- Rated output power 180W, 360W, 720W, 1080W
- Wide voltage and current range, high efficiency power supply
- CV, CC priority mode selection, better protection of the device under test
- Load transient recovery time (load change from 50~100%) <1ms
- Adjustable slew rate of output voltage and current
- Set and read back resolution: 1 mV, 1 mA
- Internal output discharge circuit, for faster output voltage step-down
- Remote voltage measurement
- List function up to 50 steps (By manual input or imported via USB)
- External analog voltage and resistance control of voltage or current output
- External voltage and current monitoring output
- OVP, OCP, LPP, OTP protection.
- 2.4-inch OLED liquid crystal display with high brightness 170-degree viewing angle
- Standard interface USB interface LAN Analog control interface
- Optional USB GPIB module
- 1/2, 1/3, 1/6 mounting case size
- Embedded web server provides remote control via web browser without the need for drivers or software
Hardware details
The SPS5000X programmable DC switch mode power supply series offer a wide range of output power with single and multi-channel output configurations and constant power capabilities. The series includes 16 models with voltages up to 160 VDC and power ratings up to 1080 W. The SPS5000X power supplies can be connected in series with 2 units or in parallel with 3 units. This allows for 0-320V and 0-270A and a maximum combined power of 3240 W. The SPS5000X feature a 2.4-inch high brightness OLED display and a user-friendly computer interface for easy control and power monitoring. Further, the power supplies offer high-resolution voltage and current settings, adjustable slew rates, list sequence programming via the front panel or standard LAN/USB interface, analog control, and overvoltage, current, power and temperature protection. The SPS5000X Series is the ideal choice for a variety of demanding markets, including commercial industrial, education, energy and power generation, general laboratory testing, LED lighting industry, and automotive electronics.
Product highlights
Constant output power
Automatic regulation of current & voltage for constant output power.
Intuitive operation
Can be operated via the front panel or web interface. Supports USB.
Device combination
Combination of different SPS5000X series devices possible to get up to 3240W output power.
Web interface
Control the device via the intuitive to use web interface.
CV/CC Priority Mode
Automatic control and change of CC & CV.
Command list function
Manual list sequence programming & import of command lists via USB import.
Technical Data
| Model comparison | Channel output | Display | Resolution | Setting Accuracy | Readback accuracy |
|---|---|---|---|---|---|
 SPS5041X | 1 channel, 40 V/30 A/360 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 30 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 40 mA |
 SPS5042X | 1 channel, 40 V/60 A/720 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 60 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 70 mA |
 SPS5043X | 1 channel, 40 V/90 A/1080 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 100 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 100 mA |
 SPS5044X | 2 channels, 40 V/30 A/720 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 30 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 40 mA |
 SPS5045X | 3 channels, 40 V/30 A/1080 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 30 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 40 mA |
 SPS5051X | 1 channel, 50 V/10 A/180 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 10 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 20 mA |
 SPS5081X | 1 channel, 80 V/15 A/360 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 10 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 20 mA |
 SPS5082X | 1 channel, 80 V/30 A/720 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 30 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 40 mA |
 SPS5083X | 1 channel, 80 V/45 A/1080 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 40 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 50 mA |
 SPS5084X | 2 channels, 80 V/15 A/720 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 10 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 20 mA |
 SPS5085X | 3 channels, 80 V/15 A/1080 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 10 mV Current: 0.1 % ± 10 mA | Voltage: 0.1 % ± 20 mV Current: 0.1 % ± 20 mA |
 SPS5161X | 1 channel, 160 V/7.5 A/360 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 5 mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 5 mA |
 SPS5162X | 1 channel, 160 V/15 A/720 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 15 mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 15 mA |
 SPS5163X | 1 channel, 160 V/22.5 A/1080 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 20 mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 20 mA |
 SPS5164X | 2 channels, 160 V/7.5 A/720 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 5 mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 5 mA |
 SPS5165X | 3 channels, 160 V/7.5 A/1080 W | 2.4-inch OLED screen | 1mV/1mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 5 mA | Voltage: 0.1 % ± 100 mV Current: 0.1 % ± 5 mA |
